Modules
Figure 7 - 2
RAID Created
7
7 - 6 Setting Up SATA RAID or AHCI Modes
10. This will now return to the main menu.
Intel(R) Matrix Storage Manager option ROM v6.0.0.1022 ICH8R wRAID5
Copyright (C) 2003-06 Intel Corporation. All Rights Reserved.
RAID Volumes:
ID Name
0 My RAID
Physical Disks:
Port Drive Model
0 FUJITSU MHV2040B NW56T5C25FAF
1 FUJITSU MHT2060B NR0UT52256W7
[ ]-Select
11. Select 4.Exit and press Enter, then press Y to exit the RAID configuration menu.
12. As the computer starts up, press a key when you see the message "Press any
key to boot from CD".
13. Press Enter to continue installing the operating system as normal (see your
Windows documentation if you need help on installing the Windows OS).
14. Install the Windows drivers from the Device Drivers & Utilities + User's Manual
DVD-ROM as per Table 4 - 1, on page 4 - 3
driver - see "Intel Matrix Driver Installation" on page 7 -
[ MAIN MENU ]
1. Create RAID Volume
2. Delete RAID Volume
3. Reset Disks to Non-RAID
4. Exit
[ DISK/VOLUME INFORMATION ]
Level Strip Size
RAID1(Mirror) N/A 55.9GB
Serial # Size
93.2GB
55.9GB
[ESC]-Exit [ENTER]-Select Menu
(make sure you install the Intel Matrix
Status Bootable
Normal Yes
Type/Status(Vol ID)
Member Disk(0)
Member Disk(0)
7).
