Interface (Ports & Jacks)

Ports and Jacks

Item

Card Reader

Cable (CATV)

Antenna Jack

DC-In Jack

A

DVI-Out Port

External Monitor Port

A - 2 Interface (Ports & Jacks)
The card reader allows you to use the following digital storage cards:
MMC (MultiMedia Card)
SD (Secure Digital)
MS (Memory Stick)
MS (Memory Stick Pro)
Use this jack to connect a CATV cable if you have included the optional Mini-PCI TV Tuner in
your purchase.
Plug the supplied AC/DC adapter into this jack to power your computer.
The DVI-Out (Digital Visual Interface) Port (at the rear of the computer) allows you to connect an
external monitor, or Flat Panel Display, to allow dual video or simultaneous display on the LCD
and external monitor/FPD (see
an older type of monitor you will need to use a converter to convert the signal from DVI to VGA.
The External Monitor Port (on the left of the computer) allows you to connect an external monitor,
or Flat Panel Display, to allow dual video or simultaneous display on the LCD and external
monitor/FPD (see "- Display Modes Available" on page 1 -
Description
RS MMC (requires PC adapter)
Mini SD (requires PC adapter)
MS Duo (requires PC adapter)
"- Display Modes Available" on page 1 - 16). If you are using
16).
