Domain IDs

Domain IDs are assigned dynamically when a switch is enabled. However, the
Domain ID can be set manually in order to control the number or to resolve a
Domain ID conflict when merging fabrics.

Display a Current List of Domain IDs

1. Log into a switch.
2. Enter the fabricshow command.
Fabric information is displayed, including the Domain ID (D_ID).
Example:
switch:admin> fabricshow
Switch ID Worldwide Name Enet IP Addr FC IP Addr Name
-------------------------------------------------------------------------
3: fffc43 10:00:00:60:69:10:60:1f 192.168.64.187 0.0.0.0 "sw187"
2: fffc42 10:00:00:60:69:00:05:91 192.168.64.60 192.168.65.60 "sw60"
1: fffc41 10:00:00:60:69:00:02:0b 192.168.64.180 192.168.65.180 >"sw180"
0: fffc40 10:00:00:60:69:00:06:56 192.168.64.59 192.168.65.59 "sw5"
The Fabric has 4 switches
Group ID Token
-----------------
0: fffb01 40:05:00:00:10:00:00:60:69:00:00:15
The fields in the fabricshow command are described as follows:
Switch ID
World Wide Name
Enet IP Addr
FC IP Addr
Name
Fabric OS Procedures Version 3.1.x/4.1.x User Guide
The switch Domain_ID and embedded port D_ID.
The switch WWN.
The switch ethernet IP address.
The switch FC IP address.
The switch symbolic name. An arrow (>) indicates the
principal switch.
