HP StorageWorks MSA 2/8 - SAN Switch User Manual page 103

Note:
stops traffic flow through the switch until the switch is rebooted.
1. Create a serial connection to the switch. If Secure Mode is enabled, connect to
2. Reboot the switch by entering the reboot command.
3. Press ESC within four seconds after the message Press escape
The following options are available:
4. Enter "3" at the prompt to enter the command shell.
Fabric OS Procedures Version 3.1.x/4.1.x User Guide
Setting the Boot PROM password requires accessing the boot prompt, which
the Primary FCS switch. If the switch does not have a serial port, contact
Technical Support.
a. Connect the serial cable to the serial port on the switch and to an RS-232
serial port on the workstation.
If the serial port on the workstation is RJ-45 instead of RS-232, remove
the adapter on the end of the serial cable and insert the exposed RJ-45
connector into the RJ-45 serial port on the workstation.
b. Disable any serial communication programs running on the workstation.
c. Open a terminal emulator application (such as HyperTerminal on a PC, or TERM
or Kermit in a Unix environment), and configure the application as follows:
In a Windows 95, 98, 2000, or NT environment:
Parameter
Bits per second:
Databits:
Parity:
Stop bits:
Flow control:
In a UNIX environment, enter the following string at the prompt:
tip /dev/ttyb -9600
within 4 seconds... displays.
1) Start system.
2) Recovery password.
3) Enter command shell.
Value
9600
8
None
1
None
Basic Security in FOS
103
