SNMP trap configuration parameters

SNMP trap configuration lets you set up to eight trap destinations. Choose from Trap 1 through Trap
8 to configure each trap.
Table 29 SNMP trap configuration parameters
Parameter
Trap n enabled
Trap address
1
Trap port
Trap version
1
Trap address (other than 0.0.0.0.) and trap port combinations must be unique. For example, if trap 1 and trap 2 have the
same address, they must have different port values. Similarly, if trap 1 and trap 2 have the same port value, they must have
different addresses.

Management Information Base

This section describes the QLogic MIB.

Network port table

The network port table contains a list of network ports that are operational on the router. The entries
in this table include the management port (labeled MGMT) and the GbE ports (labeled GE1 and
GE2).
qsrNwPortTable
Syntax
Access
Description
qsrNwPortEntry
Syntax
Access
Description
A network port entry consists of the following sequence of objects:
qsrNwPortRole
216 Simple Network Management Protocol setup
Table 29 describes the parameters for configuring an SNMP trap.
Description
1
Enables or disables trap n. If disabled, the trap is not configured.
Specifies the IP address to which the SNMP traps are sent. A maximum of eight trap
addresses are supported. The default address for traps is 0.0.0.0.
Port number on which the trap is sent. The default is 162. If the trap destination is not
enabled, this value is 0 (zero). Most SNMP managers and management software
listen on this port for SNMP traps.
Specifies the SNMP version (1 or 2) with which to format traps.
SEQUENCE OF QsrNwPortEntry
Not accessible
Entries in this table include the management port, and the iSCSI ports on
the router.
QsrNwPortEntry
Not accessible
Each entry (row) contains information about a specific network port.
QsrPortRole
