O
C
NBOARD
ONNECTORS
Connector
+12V_CONN
1394_1
ATXPWR
CD_IN
COM 2
CPUFAN
FIR
F_AUDIO
F_PANEL
IDE 1-2
KBMS Header
LPT
LVDS
SATA1 and 2
SMBus_Header
SYSFAN
USB 3-4/5-6/7-8
VIP_2
WOL
O
J
NBOARD
UMPERS
Jumper
CLEAR_CMOS
J1
SPDIF_SEL
WP
Description
12V Power connector
IEEE 1394 connector
Power cable connector
Onboard CD audio cable connector
COM port 2 connector
CPU fan connector
Fast Infrared Radiation connector
Front Audio connector
Front panel connector
IDE drive connectors
Keyboard and Mouse connector
Parallel port connector
LVDS connector
Serial ATA 1 and 2 connectors
SMBus connector
System fan connector
Universal Serial Bus 2.0 connectors 3-4/5-6/7-8
VIP connector
Wake On LAN connector
Description
Reset CMOS settings
IDE selector
S/PDIF selector
BIOS write protection setting
7
Specifications
Page
12-13
31-32
17-18
31-32
31-32
12
28
33-34
26-27
23-24
38, 40
28-29
36-37
25
33
12
30
35
31
Page
38-39
38, 40
38, 40
38, 40
