Back Panel I/O Ports
1 x PS/2 mouse port and 1 x PS/2 keyboard port
1 x RJ-45 LAN port
1 x Serial port
2 x USB 2.0 ports
1 x RCA port (SPDIF or TV out)
1 x S-Video port
1 x VGA port
3 x Audio Jacks: line-out, line-in and mic-in (Horizontal, Smart 5.1
Support)
Onboard I/O Connectors
3 x USB pin headers for 6 additional USB 2.0 ports
1 x IEEE 1394 pin header
1 x Serial port pin header for COM2
1 x VIP pin header
1 x Front Panel audio pin header (Mic-in and Line-out)
1 x CD audio-in connector
1 x FIR pin header
1 x KBMS pin header (KB/MS or CIR)
1 x LPT port pin header
1 x Wake On LAN connector
2 x Fan connectors (CPU Fan and System Fan)
1 x +12V power connector
1 x SMBus connector
1 x LVDS (function to be supported w/ an additional daughter card)
1 x WP pin header
BIOS
Award BIOS with 4/8Mbit flash memory capacity
ACPI2.0, SMBIOS2.1 and DMI2.2
Form Factor
Mini-ITX (6 layers)
17 cm X 17 cm
3
Specifications
