Wake-On LAN: WOL
This connector allows you to connect a network card with the Wake-On LAN
function. The connector will power up the system when a signal is received
through the network card. Please note that the function of ACPI WOL may
be disabled when users will unplug the power cord or turn off the power
button manually.
1
COM2
Wake-On LAN connector: WOL
Pin
Signal
1
+5VDUAL
2
GND
3
WOL IN
1
1394
Description
VCC
Ground
Wake on LAN Input
31
C3 Processor
TM
1
WOL
Installation
