- Page 1 Operating Guide EPIA SP-Series Mini-ITX Mainboard August 17, 2004 Version 1.00...
-
Page 2: Table Of Contents
EPIA SP-Series Operating Guide Table of Contents TABLE OF CONTENTS ..................................I VIA EPIA SP-SERIES OVERVIEW.............................. 1 VIA EPIA SP-SERIES LAYOUT ..............................2 VIA EPIA SP-SERIES SPECIFICATIONS ..........................3 VIA EPIA SP PROCESSOR SKUS ..............................4 VIA CN400 CHIPSET OVERVIEW .............................. 5 VIA EPIA SP-SERIES I/O BACK PANEL LAYOUT ......................... -
Page 3: Via Epia Sp-Series Overview
EPIA SP-Series Operating Guide VIA EPIA SP-Series Overview The VIA EPIA SP-Series Mini-ITX Mainboard is an ultra compact x86 motherboard design with unprecedented expandability and versatility for today’s ever-growing need of embedded applications. The mainboard is based on the VIA CN400 chipset featuring an embedded hardware MPEG-2 decoder / MPEG-4 accelerator and integrated VIA UniChrome™... -
Page 4: Via Epia Sp-Series Layout
EPIA SP-Series Operating Guide VIA EPIA SP-Series Layout August 17, 2004 - 2 - Version 1.00... -
Page 5: Via Epia Sp-Series Specifications
EPIA SP-Series Operating Guide VIA EPIA SP-Series Specifications - VIA C3/EDEN EBGA Processor Processor Chipset - VIA CN400 North Bridge - VT8237 South Bridge System Memory - 1 DDR400/333/266 DDR SDRAM slot - Up to 1GB memory size - Integrated VIA UniChrome™ Pro AGP Graphics Expansion Slot - 1 PCI Onboard IDE... -
Page 6: Via Epia Sp Processor Skus
EPIA SP-Series Operating Guide VIA EPIA SP Processor SKUs The VIA EPIA SP-Series is available in two different speed grades. The VIA EPIA SP8000E utilizes VIA’s ultra low power VIA Eden™ ESP processor while the VIA EPIA SP13000 utilizes the robust VIA C3™ processor. -
Page 7: Via Cn400 Chipset Overview
EPIA SP-Series Operating Guide VIA CN400 Chipset Overview The VIA CN400 Chipset is designed to enable high quality digital video streaming and DVD playback in a new generation of fanless, small form factor PCs and IA devices. The CN400 features the embedded VIA UniChrome™... -
Page 8: Via Epia Sp-Series I/O Back Panel Layout
EPIA SP-Series Operating Guide VIA EPIA SP-Series I/O Back Panel Layout The EPIA SP’s ultra compact 17cm x 17cm, integrated design supports all the standard legacy x86 connectivity options as well as USB 2.0, VGA port, RJ45 LAN port, serial port and VIA 6 channel AC’97 audio. -
Page 9: Via Epia Sp-Series Layout Diagram & Mounting Holes
EPIA SP-Series Operating Guide VIA EPIA SP-Series Layout Diagram & Mounting Holes August 17, 2004 - 7 - Version 1.00... -
Page 10: Via Epia Sp-Series Layout Diagram & Height Distribution
EPIA SP-Series Operating Guide VIA EPIA SP-Series Layout Diagram & Height Distribution August 17, 2004 - 8 - Version 1.00... -
Page 11: Noise Level Data
EPIA SP-Series Operating Guide Noise Level Data VIA and the EPIA series have been at the forefront of the quiet computing initiative. The VIA EPIA SP- Series has been designed to be totally non-obtrusive with noise levels equivalent to a person whispering. With noise levels ranging from the totally silent VIA EPIA SP8000E to 25dBA for the VIA EPIA SP13000, a new wave of system design innovation and exciting opportunities are being created in an almost limitless number of emerging new market segments - ranging from fanless thin clients, flat panel small... -
Page 12: Power Consumption
EPIA SP-Series Operating Guide Power Consumption Power consumption tests were carried out comparing the VIA EPIA SP13000 (running the 1.3GHz VIA C3™ processor) and the VIA EPIA SP8000E (running the 800MHz VIA Eden™ ESP processor). The following tables are a comprehensive breakdown of the EPIA platform’s voltage, amp and wattage values while running common system applications. -
Page 13: Via Epia Sp 8000E
EPIA SP-Series Operating Guide VIA EPIA SP 8000E A. Playing DVD – Power DVD 4.0 Voltage Measured Amp. Watts Main Board +3.3V 9.785 3.295 2.970 Main Board +5V 5.492 5.034 1.091 Main Board 5VSB 0.312 5.092 0.061 Main Board +12V 1.487 12.128 0.123... -
Page 14: Power Specifications
EPIA SP-Series Operating Guide Power Specifications The EPIA SP utilizes an industry standard 20-pin ATX main connector to the power supply. Due to the EPIA SP platform’s ultra low power requirements, a 90 – 120 Watt ATX power supply is ample for even the heaviest of multimedia system applications. -
Page 15: Via Epia Sp-Series Microsoft And Linux Driver Support
EPIA SP-Series Operating Guide VIA EPIA SP-Series Microsoft and Linux Driver Support Microsoft Driver Support VIA EPIA SP-Series offer full support for the complete range of Microsoft operating systems. For standard operating systems, Windows 98/Me/2000/XP latest drivers downloads can be found in the VEPD website at www.viaembedded.com. -
Page 16: Contact
EPIA SP-Series Operating Guide Contact For more information on the VIA EPIA SP-Series Mini-ITX Mainboard contact your sales representative or visit our website at www.viaembedded.com Taiwan 440 Mission Court, Suite 220 8F, 533, Chung Cheng Road Fremont, CA 94539 Hsin Tien, Taipei Tel: (510) 683 3300 Tel: (02) 2218 5452 Fax: (510) 687 4654...
