Fast IrDA Infrared Module Connector: FIR
This pin header is used to connect to an IrDA module. The BIOS settings
must be configured to activate the IR function.
Pin
Signal
1
+5V
2
IRRX1
3
IRRX
4
GND
5
IRTX
1
FIR
1
LPT
Description
VCC
FIR/SIR Data Receive
SIR Data Receive
Ground
FIR/SIR Data Transmit
1
SPDIF
