Installation
B P P
ACK ANEL ORTS
The back panel has the following ports:
PS/2 Mouse COM1 RJ45
RCA / SPDIF
PS/2 Keyboard
VGA Out USB S-Video Line-Out Line-In Microphone

Keyboard and Mouse

The green 6-pin connector is for a PS/2 mouse. The purple
connector is for a PS/2 keyboard.
VGA Out
The 15-pin female VGA connector can be used
to connect to any analog VGA monitor.
Serial port: COM 1
This 9-pin COM 1 port is for pointing devices or
other serial devices.
