PNP/PCI C
ONFIGURATIONS
PNP OS Installed
Reset Configuration Data
Resources Controlled by
IRQ Resources
Assign IRQ for VGA
Assign IRQ for USB
: Move
Enter: Select
F5: Previous Values
Note:
This section covers some very technical items and it is strongly
recommended to leave the default settings as is unless you are an
experienced user.
PNP OS Installed
Setting
Yes
No
Reset Configuration Data
This field should usually be left "Disabled".
Setting
Enabled
Disabled
Phoenix - AwardBIOS CMOS Setup Utility
PnP / PCI Configurations
[No]
[Disabled]
[Auto(ESCD)]
Press Enter
[Enabled]
[Enabled]
+/-/PU/PD: Value
F6: Fail-Safe Defaults
Description
BIOS will only initialize the PnP cards used for booting
(VGA, IDE, SCSI). The rest of the cards will be initialized
by the PnP operating system
BIOS will initialize all the PnP cards
Description
Resets the ESCD (Extended System Configuration Data)
after exiting BIOS Setup if a newly installed PCI card or
the system configuration prevents the operating system
from loading
Default setting
69
Menu Level
Select Yes if you are using a
Plug and Play capable
operating system. Select No if
you need the BIOS to
configure non-boot devices.
F10: Save
ESC: Exit
F7: Optimized Defaults
BIOS Setup
Item Help
F1: General
Help
