Cabinet View
Table 4-10. Configuration Data
Data Area
CABINET
DESCRIPTION
CARRIER
DESCRIPTION
Field Description
This area of the screen includes details
about the current cabinet.
CABINET The cabinet number.
CABINET The type of cabinet layout:
LAYOUT
CABINET TYPE The type of cabinet:
ROOM The room where the cabinet is located
(taken from PBX administration.)
FLOOR The floor where the cabinet is located
(taken from PBX administration.)
BUILDING The building where the cabinet is
located (taken from PBX administration.)
This area of the screen includes details
about the carrier.
Carrier The carrier label.
Carrier Type The type of carrier:
Port Network The number of the port network, 1 - 44
Number
five-carrier
single-carrier-stack
enhanced-single-carrier-stack
small
very-small
processor
expansion-port-network
processor
dup-sw-node
switch-node
port
fan
expansion-control
not-used
Issue 2 April 1996
4-13
