The Configuration Map

Screen Heading for Switch View

Immediately below the menu bar, the Switch View displays general information
about the PBX. Double click on the icon for more information:
Table 4-4. Screen Heading
Data
Application
Name
Switch Name
Switch Type
Number of
Cabinets
Found
Circuit Pack
Mismatches

Alarms for Switch View

The color-coded alarms on the right side of the screen display the number of
major, minor, and warning alarms as follows:
Column
External
Switch
Cabinet
4-6
Issue 2 April 1996
Description
DEFINITY G3 Fault Management
The name of the PBX as it appears on the NMS when the
PBX is administered as a node on the network. This
information is passed from the NMS.
The type of PBX (the object ID from the Proxy Agent MIB), as
it is administered on the Proxy Agent.
The number of cabinets that Fault Management recognizes.
Valid values are:
A number from 1 - 44
Blank, if Fault Management cannot find any cabinets for
the PBX.
The number of circuit packs with a mismatch between the
type that is inserted into the cabinet slot and the type that is
administered for that slot.
Fault Management displays this field only when mismatches
exist.
Description
Alarms for the external devices. This column displays only if
there are external devices administered on the PBX.
Alarms that are on the system but are not associated with a
cabinet.
Alarms that are specifically associated with cabinet hardware.
