The Configuration Map

Faults Displayed as Colors

Fault Management shows the severity of alarm conditions with color highlighting
or grey-scale settings. (This manual uses the term color to refer to both of these
settings.) However, within the context of the configuration manager, the color
indicators are specific to the level you are viewing.
Figure 4-1 is an example of an alarms display. The color-coded alarm boxes
show the cumulative total of active alarms. Typically, alarms display on the
right-hand side of the window.
Figure 4-1. Alarms
:
For information about ...
Faults and color highlighting
The difference between cabinet and pack
alarms

Screens in the Configuration View

The configuration map displays PBX data in layers, or views. Each view is a
graphical display for one of the following hardware layers.
Switch View
Cabinet View
Circuit Pack Information
Port Information
External Devices
Individual External Devices
4-2
Issue 2 April 1996
Click here ...
Color Highlighting
Types of Alarms Reports
