The Configuration Manager

How to Close Configuration Reports

To close a report, click on Close.

Cabinet Displays

The configuration manager displays a graphic depiction of the circuit packs
within the cabinet.
When you select a filter from the Configuration menu, Fault Management
highlights the circuit packs that meet the filter criteria.
You can:
Identify how the circuit packs are configured
Clear filter highlighting

Circuit Pack Filters

Fault Management offers several predefined configuration filters. When you
select the filter type, the system:
Highlights those circuit packs that meet the filter criteria
Displays a circuit pack report
This feature is available only at the cabinet level, where you can see the graphic
depiction of the circuit packs within the cabinet.
The predefined circuit pack filters are:
Unassigned Ports
No Assigned Ports
No Available Ports
TTI Ports
Type Mismatch
Control Circuit Packs
Major Alarms
Minor Alarms
Warning Alarms
For a description of these filters, see Table 4-7.
The following figure shows a cabinet that highlights circuit packs with
Unassigned Ports. In the lower right portion of this window, a message identifies
6-12
Issue 2 April 1996
