Base View

1
2
3
Figure 1-6. Base View
Table 1-6. Base View
# Icon
1
2
3
4
1-16
Item
Battery bay
Battery release latch
Hard disk bay
Memory compartment
Battery lock
0
Description
Houses the computer's battery pack.
Releases the battery for removal.
Houses the computer's hard disk (secured
with screws).
Houses the computer's main memory.
Locks the battery in position.
Hardware Specifications and Configurations
