Processor - eMachines E644G Service Manual

System Board Major Chips
Item
Core logic
VGA
LAN
USB 2.0
USB 3.0
Super I/O controller
Bluetooth
Wireless
PCMCIA
Audio codec
Card reader
eSata

Processor

Item
CPU type AMD E350(1.6G dual core), E240(1.5G single core)
CPU package FT1 BGA 413-ball
Core Logic Two execution cores
Chipset AMD Hudson M1
1-24
AMD Hudson M1 uFCBGA-605-ball
ATI Mobility Radeon™ HD 6310M APU
ATI Mobility Radeon™ HD 6470M GPU
Atheros AR8151 for Giga LAN Controller
AMD Hudson M1
N/A
AMD Hudson M1
Atheros BU12/ Broadcom BCM2070
Atheros HB95/ HB97, Broadcom 43225
N/A
Conexant CX20584
Realtek RTS-5137
N/A
A 32-KB instruction and 32-KB data first-level cache (L1) for each core
A 256-KB shared instruction/data second-level cache (L2) for each core
Up to 4-MB shared instruction/data third-level cache (L3), shared among all
cores
Specification
Specification
Hardware Specifications and Configurations
