LCD Panel Installation

1. Put LCD panel (B) on the LCD cover.
2. Put LVDS cable (C) in the cable guides.
3. Install and secure four (4) screws (A) to the LCD panel.
4. Install LCD bezel.
ID Size
A M2.5*4.0
Machine Maintenance Procedures
(Figure 3-46)
(Figure 3-47)
(Figure
Quantity
6
3-46)
Screw Type
0
3-49
