LCD Bezel Removal

Prerequisite:
LCD (Liquid Crystal Display) Module Removal
1. Remove two screw caps. (Figure 3-40)
2. Remove two (2) screws (A) from the LCD module. (Figure 3-40)
Figure 3-40. LCD Bezel
3. Lift the bottom of the bezel up releasing it from the latches. (Figure 3-41)
Figure 3-41. LCD Bezel
Machine Maintenance Procedures
A
0
3-43
