USB Board Installation

1. Install USB board (F) on lower cover.
2. Install and secure screw (D) to lower cover.
3. Connect USB board FFC (A) to module connector (B).
4. Connect USB board FFC (A) to mainboard connector (C).
5. Install upper cover.
ID Size
D M2.5*3.0
Machine Maintenance Procedures
(Figure 3-24)
(Figure 3-25)
(Figure
(Figure
Quantity
1
3-25)
3-25)
Screw Type
0
3-29
