Base view
1
2
3
#
Icon
Item
1
Battery bay
2
Battery release lock
3
Memory compartment
Hard disk bay
4
Battery lock
Environment
•
Temperature:
•
Operating: 5 °C to 35 °C
•
Non-operating: -20 °C to 65 °C
•
Humidity (non-condensing):
•
Operating: 20% to 80%
•
Non-operating: 20% to 80%
Description
Houses the computer's battery pack.
Releases the battery for removal.
Houses the computer's main memory.
Houses the computer's hard disk (secured
with screws).
Locks the battery in position.
9
