Using the LAN MAC EEPROM Utility

Perform the following steps to write MAC (Media Access Control) information to EEPROM:
Use the MAC.BAT utility to write the MAC.CFG file to the EEPROM under DOS mode.
1. Use a text editor (Ex: Notepad) to open the MAC.CFG file. See the MAC.CFG contents in
Figure 2-25
Figure 2-25. LAN MAC EEPROM
Table 2-5. LAN MAC EEPROM
Parameter
WriteData = '001122334455'
StartAddr=7A
WriteLeng=6
KeepByte=0
2. Enter into DOS.
3.
Run the MAC.BAT file to write MAC values to EEPROM.
Figure 2-26. LAN MAC EEPROM
4.
Reboot the system when the process has completed.
System Utilities
MAC value
MAC address
MAC value length
Value not important
0
Description
2-25
