Base View - eMachines Notebook Quick Manual

Base view

1
2
3
# Icon Item
1 Battery bay
2 Battery release lock
3 Memory compartment
Hard disk bay
4 Battery lock
Environment
•
Temperature:
• Operating: 5 °C to 35 °C
• Non-operating: -20 °C to 65 °C
•
Humidity (non-condensing):
• Operating: 20% to 80%
• Non-operating: 20% to 80%
Description
Houses the computer's battery pack.
Releases the battery for removal.
Houses the computer's main memory.
Houses the computer's hard disk (secured
with screws).
Locks the battery in position.
9
4
