Touchpad Removal

Prerequisite:
Upper Cover Removal
1. Find touchpad (C) on upper cover.
2. Remove touchpad FFC (A) from touchpad. (Figure 3-23)
3. Disconnect and remove touchpad FFC (A) from touchpad connector (B). (Figure 3-23)
D
C
Figure 3-23. Touchpad
4. Lift plastic cover (C) securing the grounding tape and remove grounding tape (D) from
touchpad. (Figure 3-23)
5. Remove touchpad from upper cover.

Touchpad Installation

1. Install touchpad (C) on upper cover.
2. Lift plastic cover (C) and install grounding tape (D) onto touchpad. (Figure 3-23)
NOTE:
NOTE:
Make sure the grounding tape is touching the connective section of the touchpad as
shown in Figure 3-23.
3. Connect touchpad FFC (A) to touchpad connector (B). (Figure 3-23)
4. Install touchpad FFC to touchpad. (Figure 3-23)
5. Install upper cover.
