LCD (Liquid Crystal Display) Module Removal

Prerequisite:
Mainboard Removal
1. Remove four (4) screws (A) from LCD hinges. (Figure 3-36)
A
Figure 3-36. LCD Hinge Screws
2. Remove the upper cover from the LCD module. (Figure 3-37)
Figure 3-37. LCD Module
Machine Maintenance Procedures
0
A
3-39
