Keyboard Removal

Prerequisite:
Battery Pack Removal
1. Release seven (7) latches from the keyboard. (Figure 3-5)
Figure 3-5. Keyboard Latches
2. Turn the keyboard over so that the keys are face down on the palm rest (C). (Figure 3-6)
3. Disconnect keyboard FPC (A) from mainboard connector (B). (Figure 3-6)
C
C
Figure 3-6. Keyboard FPC
3-10
B
A
Machine Maintenance Procedures
