Upper Cover Removal - eMachines E644G Service Manual

Upper Cover Removal

Prerequisite:
HDD (Hard Disk Drive) Module Removal
1.
Remove fourteen (14) securing screws from the lower cover
Figure 3-16. Lower Cover Screw Location
2.
Remove eight (8) securing screws (A) from the upper cover
Figure 3-17. Upper Cover Screw Location
Machine Maintenance Procedures
. (Figure 3-16)
. (Figure 3-17)
A
0
3-21
