LCD Bracket Removal

Prerequisite:
LCD Panel Removal
1. Remove the six (6) screws (A). (Figure 3-48)
A
Figure 3-48. LCD Bracket
2. Remove LCD bracket from the LCD panel.

LCD Bracket Installation

1. Put LCD bracket on the LCD panel. (Figure 3-48)
2. Install and secure six (6) screws (A) to the LCD bracket. (Figure 3-48)
3. Install LCD panel to LCD cover.
ID Size
A M2.0*3.0
3-50
Quantity
6
Machine Maintenance Procedures
0
A
0
Screw Type
