ODD Module Installation

1. Install ODD bezel (E) on ODD
2. Install ODD bracket (D) on ODD module and secure two (2) screws (C).
3. Insert ODD module (B) into ODD module bay.
4. Install and secure screw (A) to lower cover.
5. Install battery.
ID Size
A M2.5*6.0
C M2.0*3.0
Machine Maintenance Procedures
module.(Figure 3-8)
(Figure
(Figure 3-7)
Quantity
1
2
(Figure
3-7)
Screw Type
0
3-8)
3-13
