Wine Storage

Door Clearance

FULL-SCALE TEMPLATE
Model 424G should extend a minimum
1
of / " beyond the front surface of
(6)
4
adjoining cabinetry to allow for the
maximum 145° door opening. The unit
can be installed flush with adjacent
cabinetry, however, there is potential
for interference with the panel if the
door is opened past 90°.
3
/
4
DOOR OPENING 145°
TOP VIEW
MODEL 424
DOOR CLOSED
"
(19) DOOR PANEL
0"
SCALE
1"
(25)
subzero.com/specs
1
/ "
2
(13)
1
/ "
4
1
/ "
8 (3)
MAXIMUM DOOR
OPENING 145°
83
(6)
