Sub-Zero BI-36UFD Design Manual page 63

Integrated Refrigeration
Maximum Door Opening
FULL-SCALE TEMPLATE
If the panel is thicker than
door stop to prevent damage to the panel and face frame
at the maximum door opening.
LINE OF INTERFERENCE
MAXIMUM 105° OPENING
1
/ "
8 (3) MINIMUM REVEAL
DOOR CLOSED
TOP VIEW—FULL-SCALE
3
/ " , use the built-in 90°
(19)
4
3
/ "
4 (19)
MAXIMUM 105° OPENING
105° OPENING
TOP VIEW—1/4 SCALE
FRAMED PANEL
MOUNTING BRACKET
INTEGRATED DOOR CLOSED
LINE OF INTERFERENCE
SIDE MOLDING AND
INSTALLATION HARDWARE
subzero.com/specs
INTEGRATED
DOOR
0"
63
LINE OF
INTERFERENCE
1"
(25)
SCALE
