Sub-Zero BI-36UFD Design Manual page 43

Built-In Refrigeration
PROFILE OF 3
/ "
4
AND TUBULAR HANDLE
Dual Installation—Flush Inset
FULL-SCALE TEMPLATE
Typical flush inset dual installation with
filler strip at maximum 110° door
opening. Depending on panel thickness,
a 90° door stop may be required.
0"
FLUSH INSET
TOP VIEW
(19) FLUSH INSET PANEL
1"
(25)
SCALE
FILLER STRIP
1
1 / "
(38)
2
1
/ "
(13)
2
43
subzero.com/specs
DOOR
CLOSED
DOOR
OPEN 110°
