PRO 48 Refrigeration
Planning Information
PRO 48 models can be used freestanding or installed as a
standard or flush built-in application. For standard built-in
installations, the face frame of the unit will extend 2"
beyond cabinetry. In flush built-in installations, the front of
the face frame will be flush with surrounding cabinetry.
ELECTRICAL REQUIREMENTS
For PRO 48 models, the electrical supply should be
located within the shaded area shown in the illustration
below. Follow the National Electrical Code and local codes
and ordinances when installing the receptacle. A separate
circuit, servicing only this appliance, is required. A ground
fault circuit interrupter (GFCI) is not recommended and
may cause interruption of operation.
Electrical Requirements
Power Supply
Circuit Breaker
Receptacle
FRONT VIEW
7"
E
(178)
6"
(152)
1
75 / "
2
(1918)
FROM
FLOOR
Location of electrical supply.
(51)
115 V AC, 60 Hz
15 amp
3-prong grounding-type
PLUMBING REQUIREMENTS
PRO 48 models come with an automatic ice maker and a
water filtration system. The water supply line should be
located within the shaded area shown in the illustration
below. The water supply line should be connected to the
house supply with an easily accessible shut-off valve
between the supply and the unit. Do not use self-piercing
valves. A saddle valve kit is available through your author-
ized Sub-Zero dealer. The water line must not interfere
with installation of the anti-tip bracket.
IMPORTANT NOTE: A reverse osmosis system can be
used provided there is constant water pressure of 35 psi
to 120 psi
(2.4 bar) (8.3 bar)
In this application, the water filtration system must be set
to bypass mode. This is achieved by removing the water
filter cartridge. Refer to the PRO 48 installation guide
packed with the unit for detailed instructions. A copper
line is not recommended for this application.
Plumbing Requirements
1
Water Supply Line
Water Pressure
Excess Water Line for Connection
6"
(152)
3
5 / "
16
3"
(76) (132)
FLOOR
FRONT VIEW
Location of water supply.
supplied to the unit at all times.
/ " OD copper, braided stainless steel
4
or PEX tubing
35–120 psi
(2.4–8.3 bar)
48
36"
(914)
