Sub-Zero BI-36UFD Design Manual page 41

Built-In Refrigeration
Flush Inset Application
FULL-SCALE TEMPLATE
For panels thicker than
a 90° door stop may be required
to prevent interference with
adjacent cabinets.
1"
(25) THICK
PANEL
3 / "
4 (19) THICK
FLUSH INSET PANEL
(TYPICAL)
1
/ "
4 (6) BACKER
PANEL
DOOR OPENING 110°
TOP VIEW
24"
(610)
TO BACK WALL
3
/ " ,
(19)
4
3
2 / "
16 (56)
ASSUMES
3
/ "
4 (19)
FLUSH INSET
PANEL
THICKNESS
1
1 / "
4 (32)
41
subzero.com/specs
0" 1"
(25)
SCALE
