Wine Storage
Integrated Panels
MODELS 427G AND 427RG
The integrated full panels or frame panels for glass doors
for these models will follow some of the identical planning
processes used with the integrated line. The installation of
the door panels is completely different, however. Rather
than using the mounting hardware we used with the inte-
grated line, door panels for both models 427G and 427RG
will be applied with screws applied through our door.
The drawer panels for the model 427RG will be applied
using the integrated technique of mounting brackets.
IMPORTANT NOTE: The depth of models 427G and
427RG is 24" from the front of the unit to its back.
(610)
You must allow for the thickness of the panel you are
applying when planning for the finished rough opening
depth if you want the front panel to be flush with sur-
rounding cabinetry. You may have to move the unit back
into the drywall or bring the cabinets forward. Refer to the
integrated section.
Panel dimensions listed in the chart assume the models
finish off at 80" in height overall and have a 4"
(2032)
toe kick for the model 427G. If you finish off at 84"
for instance, you must add an additional 4"
finished height of the panel and 4"
Likewise, if you allow for a 6"
427G, you must subtract 2"
The height of the door panel for models 427G and 427RG
can extend beyond the typical panel height, provided you
do not exceed the panel weight limit. Refer to specifica-
tions on page 59 of the integrated section.
The toe kick area on model 427G cannot be larger than 6"
, and on model 427RG, no larger than 9"
(152)
kick area for either model cannot be less than 4"
If you are installing an optional lock kit on models 427G
or 427RG, you may have to order door panels that exceed
the 80" finished height. Consult the lock kit installa-
(2032)
tion instructions and see if your panels will allow for an
adequate installation. These instructions are available on
our website, subzero.com.
(2134)
to the
(102)
to the top rail.
(102)
toe kick for the model
(152)
from the bottom rail.
(51)
. The toe
(229)
(102)
Integrated Panels
427G
Door
427RG
Door
Top Drawer
Bottom Drawer
Panel Requirements
MIN WIDTH
Stiles
Top Rail
Bottom Rail (427G)
Bottom Rail (427RG)
MAX PANEL WEIGHT
Door Frame
Drawer Panel (427RG)
MIN PANEL THICKNESS
All Panels
DUAL INSTALLATIONS
(102)
For information on dual installations for models 427G and
,
427RG, refer to the integrated dual installations section on
page 61.
.
73
subzero.com/specs
W H
3 7
26 / " 75 / "
(679) (1927)
4 8
W H
3 3
26 / " 45 / "
(679) (1153)
4 8
3 9
26 / " 13 / "
(679) (345)
4 16
3 11
26 / " 16 / "
(679) (424)
4 16
1
2 / "
(57)
4
3
3 / "
(95)
4
8"
(203)
3"
(76)
20 lbs
(9 kg)
12 lbs
(5 kg)
5
/ "
(16)
8
