Sub-Zero BI-36UFD Design Manual page 77

Wine Storage
Model WS-30
FLUSH INSET PANEL
Illustrations A–D provide panel offsets and reveals for
model WS-30 in a flush inset application. Refer to the
chart below for reference to the illustrations.
For additional information on panel reveals, visit the speci-
fication library section of our website, subzerotrade.com.
Panel Offsets
MODEL WS-30
Door / Grille Sides
Grille Top
Grille Bottom / Door Top
Door Bottom
TOP VIEW
DOOR / DRAWER / GRILLE
BACKER
CABINETRY
SPACER
FLUSH INSET PANEL
5
/ "
16 (8)
1
/ "
2
(13)
5
/ "
8
(16)
Illus. A
5
/ "
16
GRILLE
5
/ "
(8) 32
(4)
1
/
2
DOOR
3
/ "
32
5
/ "
16 (2)
(8)
SIDE VIEW
Illus. C
CABINETRY
5
GRILLE
Illus. B
DOOR /
DRAWER
"
(13)
SIDE VIEW
Illus. D
DUAL INSTALLATIONS
When two models WS-30 or a model WS-30 and built-in
unit are installed side by side, a dual installation kit may
be required. Contact your authorized Sub-Zero dealer for
the proper components and installation instructions. For
questions relative to the installation, call Sub-Zero at
800-222-7820. For local dealer information, visit the find a
showroom section of our website, subzero.com.
Illus.
DUAL STANDARD INSTALLATIONS
A
Two framed, overlay or stainless steel units may be placed
B
side by side in a dual installation. Some dual standard
C
installations will require a dual installation kit, available
D
through your authorized Sub-Zero dealer.
A custom filler strip can be used in between two units in a
framed, overlay or stainless steel design application. It is
recommended that the filler strip be at least 2"
1
/ "
2 (13)
to prevent condensation between the units. Be sure to add
the filler strip width to your rough opening width.
1
/ "
8
/ "
16 (3)
Dual installations without a filler strip can only be accom-
(8)
plished using two units with opposite hinges as shown in
illustration A below. The dual installations shown in illus-
trations B and C require a filler strip.
SIDE VIEW IMPORTANT NOTE: For the application shown in illustra-
tion A, a dual installation accessory kit is required.
WITHOUT FILLER STRIP
5
/ "
16
(8)
Illus. A
3
/ "
32
(2)
subzero.com/specs
FILLER STRIP REQUIRED FILLER STRIP REQUIRED
Illus. B Illus. C
77
wide,
(51)
