  • Page 1 SUB-ZERO DESIGN GUIDE...

  • Page 2: Table Of Contents

    Throughout this guide, dimensions in parentheses are millime- Sub-Zero Warranties ......92 ters unless otherwise specified.
  • Page 3 Built-In Refrigeration. For the built-in line, Sub-Zero designers and engineers took a fresh look at everything, inside and out. Exterior refinements include redesigned grilles and lower-profile hinges. Inside, new technology in food preserva- tion makes the built-in line nothing short of revolutionary.

  • Page 4: Built-In Refrigeration

    Shown with full-length handle hardware for design flexibility. and louvered grille option for Shown with pro handle option the traditional Sub-Zero look. to complement Wolf ranges.
  • Page 5 Built-In Refrigeration subzero.com/specs Flush Inset. Stainless Steel. This design For a option allows for a flush door professional look, this design and grille. Stainless steel panels requires no customization. To are available as sales acces- complement the look of Wolf sories.
  • Page 6 BI-30U 13.2 (374) (119) BI-30UG 13.1 (371) (119) 84" BI-36U 16.4 (2134) (464) (150) BI-36UG 16.3 (462) (150) " BI-36UFD 15.7 (445) (150) (1873) SIDE-BY-SIDE MODELS BI-36S 12.4 (351) (232) BI-42S 16.3 (462) (227) BI-42SID 15.8 (447) (224) BI-42SD 16.0...
  • Page 7 Built-In Refrigeration subzero.com/specs Over-and-Under Models OVERALL DIMENSIONS 30" 24" 36" 24" (762) (610) (914) (610) 84" 84" (2134) (2134) " " (1289) (1289) 23" 23" (584) (584) HEIGHT DIMENSIONS ± 1 HEIGHT DIMENSIONS ± 1 " " (13) " (13) "...
  • Page 8 (606) " " " (197) (216) (260) " " " (495) (600) (565) " " (60) (60) MODEL BI-36UFD MODEL BI-36S Overall dimensions are based on stainless steel models. For flush inset applications, add " to door clearance (13) dimensions.
  • Page 9 Built-In Refrigeration subzero.com/specs Side-by-Side Models OVERALL DIMENSIONS 42" 24" 48" 24" (1067) (610) (1219) (610) 84" 84" (2134) (2134) " " (1873) (1873) HEIGHT DIMENSIONS ± 1 HEIGHT DIMENSIONS ± 1 " " (13) " (13) " (606) (606) 4" 4"...
  • Page 10 OPENING HEIGHT SIDE VIEW FRONT VIEW Opening Width BI-36R, BI-36RG and BI-36F " (902) BI-30U and BI-30UG " (746) BI-36U, BI-36UG and BI-36UFD " (902) BI-36S " (902) BI-42S, BI-42SID and BI-42SD " (1054) BI-48S, BI-48SID and BI-48SD " (1206)

  • Page 11: Planning Information

    Do not use self-piercing valves. may cause interruption of operation. A saddle valve kit is available through your authorized Sub-Zero dealer. The water line must not interfere with installation of the anti-tip brackets. Electrical Requirements...
  • Page 12 Sub-Zero dealer. Custom cabinetry panels slide into the door to blend into the kitchen design. Shown with full-length handle and louvered grille option for the traditional Sub-Zero look. Framed Panel Requirements MAX WEIGHT PER PANEL BI-36R, BI-36RG and BI-36F...

  • Page 13: Framed Panels

    Built-In Refrigeration subzero.com/specs Framed Panels If the thickness of the custom panels is less than " they must be backed up with a sheet of shim material to MAIN FRAME MAIN FRAME TRIM TRIM build the total thickness to " .
  • Page 14 " " (132) (262) Window Cut-Out " " (648) (1008) Cut-Out Location " (132) Models BI-30U and BI-30UG REFRIGERATOR Model BI-36UFD Door Panel " " (756) (1268) FREEZER REFRIGERATOR (2 PANELS) Drawer Panel " " Door Panels " " (756)
  • Page 15 Built-In Refrigeration subzero.com/specs Framed Panels BI-36S / BI-42S / BI-42SID BI-42SD / BI-48SD BI-48S / BI-48SID Model BI-36S Models BI-48S, BI-48SID and BI-48SD REFRIGERATOR REFRIGERATOR Door Panel " " Door Panel " " (503) (1767) (724) (1767) FREEZER FREEZER Door Panel "...
  • Page 16 Built-In Refrigeration Framed Application OPTIONAL GRILLE PANEL A panel grille, providing an 84" finished height, is (2134) standard on overlay models. Optional panel grilles are available for 83" and 88" finished heights. (2108) (2235) Grille panel dimensions listed are for a standard 84" (2134) finished height.
  • Page 17 The partial framed accessory kit is available through your authorized Sub-Zero dealer. Refer to panel dimen- sions for the partial framed option below. Partial framed kit.

  • Page 18: Overlay Panels

    Built-In Refrigeration Overlay Panels If you and your client have ordered an overlay model, you will be adding panels and handles to give the unit a more custom look. The overlay panel design option is available for all built-in overlay models. For exact door panel dimen- sions, refer to overlay panel specifications on the following pages.
  • Page 19 IMPORTANT NOTE: When installing two units in a side-by- side application, refer to pages 30–31 for dual standard installations. Be aware that rough opening dimensions are different for this application. Do not exceed overlay panel dimensions, as this could cause damage to panels and the Sub-Zero unit.
  • Page 20 Models BI-30U and BI-30UG Cut-Out Location " (133) REFRIGERATOR Overlay Panel 30" " (762) (1273) Spacer Panel " " (740) (1253) Model BI-36UFD Backer Panel " " (756) (1268) FREEZER REFRIGERATOR (2 PANELS) Overlay Panel 30" 19" Overlay Panels " " (762)
  • Page 21 Built-In Refrigeration subzero.com/specs Overlay Panels BI-36S / BI-42S / BI-42SID BI-42SD / BI-48SD BI-48S / BI-48SID Model BI-36S Models BI-48S, BI-48SID and BI-48SD REFRIGERATOR REFRIGERATOR Overlay Panel " " Overlay Panel " " (510) (1772) (730) (1772) Spacer Panel " "...
  • Page 22 Built-In Refrigeration Flush Inset Application It is necessary to consider the following points when planning for a flush inset application: • The flush inset depth is 2 " deeper than the (56) standard opening. • The flush inset width is 2 "...
  • Page 23 BI-30U and BI-30UG " 32" (746) (813) " . If an 88" grille height is specified, the height (22) (2235) BI-36U, BI-36UG and BI-36UFD " 38" (902) (965) to cleat and flush inset height increases by 4" (102) BI-36S " 38"...

  • Page 24: Flush Inset Panels

    Be aware that rough opening proper fit. dimensions, panel sizes and offsets are different for this application. Do not exceed flush inset panel dimensions, as this could cause damage to panels and the Sub-Zero unit. FLUSH INSET SPACER PANEL PANEL...
  • Page 25 Built-In Refrigeration subzero.com/specs Flush Inset Panels PANEL OFFSETS TOP VIEW TOP VIEW DOOR / DRAWER / GRILLE Illustrations A–F provide panel offsets and reveals for all built-in models in a flush inset application. Refer to the chart below for reference to the illustrations relating to DOOR DOOR BACKER...
  • Page 26 " (146) (133) REFRIGERATOR Flush Inset Panel 31" " (787) (1273) Spacer Panel " " (740) (1253) Model BI-36UFD Backer Panel " " (756) (1268) FREEZER REFRIGERATOR (2 PANELS) Flush Inset Panel 31" 19" Flush Inset Panels " " (787)
  • Page 27 Built-In Refrigeration subzero.com/specs Flush Inset Panels BI-36S / BI-42S / BI-42SID BI-42SD / BI-48SD BI-48S / BI-48SID Model BI-36S Models BI-48S, BI-48SID and BI-48SD REFRIGERATOR REFRIGERATOR Flush Inset Panel " " Flush Inset Panel " " (522) (1772) (743) (1772) Spacer Panel "...

  • Page 28: Ice And Water Dispenser

    Built-In Refrigeration Ice and Water Dispenser For overlay and flush inset models, mounting placement of MODELS BI-42SD AND BI-48SD the refrigerator door handle must assure proper access to For models BI-42SD or BI-48SD, the refrigerator door the glasswell and adequate clearance under the handle. panel must include a cut-out to accommodate the dis- The handle placement illustration shows the relation of the penser glasswell and bezel.

  • Page 29: Side Panels

    IMPORTANT NOTE: If you have a model BI-30U, BI-30UG, When planning for side panels with the installation of a BI-36U, BI-36UG or BI-36UFD, extra routing will be neces- built-in model, you need to be aware of the space configu- sary to prevent the panel from hitting the refrigerator lower ration to achieve a pleasing fit.

  • Page 30: Dual Installation

    Some standard applications will require a dual installation kit, available through your authorized Sub-Zero dealer. If you are installing two units side by side in a flush inset application, refer to page 32. A custom filler strip can be used between two units in a framed, overlay or stainless steel design application.
  • Page 31 Built-In Refrigeration subzero.com/specs Dual Installation STANDARD INSTALLATION TOP VIEW 24" (610) OPENING DEPTH 24" " (610) (2127) OPENING DEPTH OPENING WIDTH OPENING HEIGHT SIDE VIEW FRONT VIEW IMPORTANT NOTE: A dual installation kit will be required Opening Widths for this installation. Two 30"...
  • Page 32 Dual installation—flush inset application. required. Dual flush inset panels and dual installation kits are avail- able through your authorized Sub-Zero dealer. Refer to Dual Installation Panel Requirements pages 34–35 for dual flush inset panel specifications and MAX WEIGHT PER PANEL page 36 for information on dual installation kits.
  • Page 33 Built-In Refrigeration subzero.com/specs Dual Installation FLUSH INSET INSTALLATION TOP VIEW " 24" (610) (665) DEPTH " 24" (610) TOP VIEW FLUSH TO CLEAT (665) OPENING INSET " FLUSH DEPTH CLEAT DEPTH (32) TWO UNITS WITH CLEAT INSET TO CLEAT " (19) PANEL DEPTH 3"...
  • Page 34 " subzerotrade.com. SIDE VIEW SIDE VIEW Do not exceed flush inset panel dimensions, as this Illus. C Illus. D could cause damage to panels and the Sub-Zero unit. DOOR / DRAWER " Panel Offsets Illus. " ALL REFRIGERATOR / ALL FREEZER...
  • Page 35 Built-In Refrigeration subzero.com/specs Dual Installation—Flush Inset Panels BI-36R / BI-36F BI-36RG BI-30U / BI-36U BI-30UG / BI-36UG BI-36R, BI-36RG and BI-36F BI-36U and BI-36UG REFRIGERATOR / FREEZER REFRIGERATOR Flush Inset Panel " " Flush Inset Panel " " (927) (1772) (927) (1273) Spacer Panel...
  • Page 36 Built-In Refrigeration Dual Installation Kit INSTALLATION WITH DUAL WIDE GRILLE INSTALLATION WITH INDIVIDUAL GRILLES This kit will replace the existing grilles that ship with the This kit is available for those who choose to utilize the units and span the entire width of both units. The kit individual grilles that ship with each unit.
  • Page 37 Accessories These optional accessories are available through your STANDARD HANDLES authorized Sub-Zero dealer. For local dealer information, Refer to the chart below for standard handle lengths visit the find a showroom section of our website, and the stud spacing of tubular and pro handles used on subzero.com.
  • Page 38 Built-In Refrigeration Framed Panel Thickness FULL-SCALE TEMPLATE OPTIONAL EXTENDED FULL-LENGTH HANDLE STANDARD FULL-LENGTH HANDLE 1" 2" 3" (25) (51) (76) " (32) PANEL 1" (25) PANEL " (19) PANEL " (13) PANEL " FRAMED PANEL DOOR PANEL THICKNESS FRAMED APPLICATION...
  • Page 39 Built-In Refrigeration subzero.com/specs Overlay Panel Thickness FULL-SCALE TEMPLATE Overlay and flush inset panels must be a minimum of " thick to support mounting the handle. Panel thickness (16) does not include backer and spacer panel. Mount handle close to the opening edge of the door. DEPTH OF TUBULAR AND PRO HANDLES 1"...
  • Page 40 Built-In Refrigeration Overlay Application FULL-SCALE TEMPLATE " (606) OVERALL WIDTH OF UNIT TO REAR OF UNIT 1" (25) THICK PANEL " (19) THICK OVERLAY PANEL (TYPICAL) " (6) BACKER PANEL 0" 1" (25) DOOR OPENING 90° TOP VIEW SCALE...
  • Page 41 Built-In Refrigeration subzero.com/specs Flush Inset Application 24" (610) FULL-SCALE TEMPLATE TO BACK WALL For panels thicker than " (19) a 90° door stop may be required to prevent interference with adjacent cabinets. " (32) " (56) ASSUMES " (19) FLUSH INSET PANEL THICKNESS 1"...
  • Page 42 Built-In Refrigeration FILLER STRIP " (32) APPROX PROFILE OF STAINLESS STEEL WRAPPED DOOR DOOR AND HANDLE CLOSED DOOR Dual Installation—Standard OPEN 110° FULL-SCALE TEMPLATE Typical framed, overlay or stainless steel dual installation with filler strip at maximum 110° door opening. Depending on panel thickness, a 90°...
  • Page 43 Built-In Refrigeration subzero.com/specs FILLER STRIP " (38) " (13) PROFILE OF 3 " (19) FLUSH INSET PANEL DOOR AND TUBULAR HANDLE CLOSED DOOR Dual Installation—Flush Inset OPEN 110° FULL-SCALE TEMPLATE Typical flush inset dual installation with filler strip at maximum 110° door opening.
  • Page 44 MODEL 648PROG...

  • Page 45: Pro 48 Refrigeration

    PRO 48 Refrigeration. Freshness finds unmistakable expression in the Sub-Zero PRO 48. An 800-pound monument to food preservation—equal parts sculpted metal design statement and culinary secret weapon. Its vast interior, like its bold exterior, is crafted of stainless steel. The PRO 48 is available with or without a glass door and may be either built in or freestanding.

  • Page 46: Pro 48 Models

    PRO 48 Refrigeration PRO 48 Models OVERALL DIMENSIONS 48" " (1219) (657) 84" (2134) " (1070) " (775) 4" (102) HEIGHT DIMENSIONS ± 1 " (13) " (767) " (606) " 21" (533) (368) SPECIFICATIONS " Capacity / Weight (781) INTERIOR CAPACITY R CU FT F CU FT...
  • Page 47 PRO 48 Refrigeration subzero.com/specs PRO 48 Models STANDARD AND FLUSH BUILT-IN INSTALLATIONS TOP VIEW OPENING DEPTH OPENING OPENING OPENING DEPTH HEIGHT WIDTH SIDE VIEW FRONT VIEW IMPORTANT NOTE: For standard built-in installations, the Opening Dimensions Standard Flush face frame of the unit will extend 2" beyond cabinetry.
  • Page 48 A saddle valve kit is available through your author- For PRO 48 models, the electrical supply should be ized Sub-Zero dealer. The water line must not interfere located within the shaded area shown in the illustration with installation of the anti-tip bracket.
  • Page 49 PRO 48 Refrigeration subzero.com/specs Accessories These optional accessories are available through your authorized Sub-Zero dealer. For local dealer information, visit the find a showroom section of our website, subzero.com. • Stainless steel side panels and top for freestanding application. •...
  • Page 50 MODELS IC-27F, 427G (WINE) AND IC-27R...

  • Page 51: Integrated Refrigeration

    Integrated Refrigeration. With custom front panels and hardware, Sub-Zero invented integrated columns, tall and drawer models that disappear into the decor. Integrated units fit flush with other cabinets, making integrated refrigeration as practical and beautiful in the master suite, bar or theatre room as in the kitchen.

  • Page 52: Overall Dimensions

    Integrated Refrigeration Overall Dimensions COLUMN MODELS 27" (686) TALL MODELS 27" 24" 27" 24" (686) (610) (686) (610) 14" 14" (356) (356) " " (41) (21) " " (1995) (1995) 81" 80" (2057) (2032) TO TOP OF TO TOP OF OPENNG "...
  • Page 53 Integrated Refrigeration subzero.com/specs Overall Dimensions 36" (914) TALL MODELS 36" 24" (914) (610) 14" (356) " (33) " (1976) 80" (2032) TO TOP OF " OPENNG (10) " " (337) (13) " " (876) (260) " (518) " (248) 4" HEIGHT DIMENSIONS ±...
  • Page 54 Integrated Refrigeration Overall Dimensions Capacity and Weight DRAWER MODELS Interior Capacity R cu ft F cu ft COLUMN MODELS 27" 24" " (686) (610) IC-27R 16.2 (459) (10) IC-27FI 16.3 (462) 27" TALL MODELS (686) 700TR 15.5 (439) " " (337) 700TFI 15.3...

  • Page 55: Opening Dimensions

    Integrated Refrigeration subzero.com/specs Opening Dimensions IMPORTANT NOTE: The depth of each integrated model is INTEGRATED MODELS 24" from the front of the unit to its back. Your design (610) may necessitate moving the unit back or cabinets forward to TOP VIEW achieve a flush fit.

  • Page 56: Electrical Requirements

    Integrated Refrigeration Electrical Requirements The electrical supply should be located within the shaded Electrical Requirements area shown in the illustrations. Follow the National Power Supply 115 V AC, 60 Hz Electrical Code and local codes and ordinances when Circuit Breaker 15 amp installing the receptacle.

  • Page 57: Plumbing Requirements

    (64) " between the supply and the unit. Do not use self-piercing (64) " valves. A saddle valve kit is available through your author- (343) ized Sub-Zero dealer. 3" (76) " (38) FLOOR " IMPORTANT NOTE: It is critical that the water line be...
  • Page 58 Integrated Refrigeration Cabinetry Applications FRAMELESS CABINETRY " " " (679) (679) (908) PANEL WIDTH PANEL WIDTH PANEL WIDTH " " " " " " (1953) (1153) (1153) " " " (2054) (2029) (2029) " " " " (345) (345) " "...
  • Page 59 Integrated Refrigeration subzero.com/specs Cabinetry Applications DOOR PANEL HEIGHT TOE KICK CLEARANCE The height of the door panel can extend beyond the The toe kick clearance can vary with the height of the typical panel height, provided you do not exceed the panel panel.
  • Page 60 Integrated Refrigeration Cabinetry Applications Integrated refrigeration is compatible with virtually any IMPORTANT NOTE: The inside edges of the rough opening style and look of cabinetry. These models can be used as well as the sides and a portion of the backside of the with framed as well as frameless cabinetry.

  • Page 61: Dual Installations

    CABINET INTEGRATED CABINET UNIT UNIT or less space between the units. Dual installation kits (51) are available through your authorized Sub-Zero dealer. DOOR IMPORTANT NOTE: If a 27" unit is installed next to (686) PANEL a 36" tall unit, the decorative front panels will align,...
  • Page 62 Accessories These optional accessories are available through your STANDARD HANDLES authorized Sub-Zero dealer. For local dealer information, Refer to the chart below for standard handle lengths visit the find a showroom section of our website, and the stud spacing of tubular and pro handles used on subzero.com.
  • Page 63 Integrated Refrigeration subzero.com/specs INTEGRATED DOOR Maximum Door Opening MAXIMUM 105° OPENING FULL-SCALE TEMPLATE If the panel is thicker than " , use the built-in 90° (19) door stop to prevent damage to the panel and face frame at the maximum door opening. LINE OF INTERFERENCE 105°...
  • Page 64 MODEL WS-30...

  • Page 65: Wine Storage

    Wine Storage. Wine finds a well-deserved place of honor in a Sub-Zero wine storage unit. Every detail is designed to ensure better wine preservation. Cherrywood-faced shelves, soft lighting, custom cabinetry if desired—Sub-Zero helps make a wine collection an element of beauty in the home.
  • Page 66 Wine Storage Overall Dimensions UNDERCOUNTER WINE STORAGE " 24" " 24" (606) (610) (384) (610) 34" " (865) (864) 4" 4" (102) (102) " (422) " (645) " (44) " (44) MODEL 315W MODEL 424G Overall dimensions are based on stainless steel panels and handles.
  • Page 67 Wine Storage subzero.com/specs Overall Dimensions FULL-SIZE WINE STORAGE 27" 24" 27" 24" (686) (610) (686) (610) 14" 14" (356) (356) " " (21) (21) " " (1995) (1995) 80" 80" (2032) (2032) OPENING OPENING " HEIGHT HEIGHT (10) " " (337) (13) "...
  • Page 68 Wine Storage Overall Dimensions Capacity and Weight FULL-SIZE WINE STORAGE Storage Capacity Bottles cu ft (750 ml) 315W 30" 24" (762) (610) 424G 427G 427RG (150) WS-30 84" Shipping Weight (kg) (2134) 315W (54) " 424G (88) (1873) 424FSG (100) 427G (179) 427RG...
  • Page 69 Wine Storage subzero.com/specs Opening Dimensions UNDERCOUNTER WINE STORAGE FULL-SIZE WINE STORAGE TOP VIEW TOP VIEW 24" 25" (635) (610) OPENING OPENING DEPTH DEPTH 24" " (610) (876) OPENING DEPTH OPENING OPENING WIDTH HEIGHT 25" 80" 27" (635) (2032) (686) OPENING DEPTH OPENING OPENING WIDTH HEIGHT...
  • Page 70 Wine Storage Opening Dimensions IMPORTANT NOTE: If an 83" grille height is specified, (2108) FULL-SIZE WINE STORAGE the opening height must be decreased by " . If an 88" (22) grille height is specified, the opening height increases (2235) TOP VIEW by 4"...
  • Page 71 Wine Storage subzero.com/specs Planning Information ELECTRICAL REQUIREMENTS Electrical Requirements Power Supply 115 V AC, 60 Hz The electrical supply should be located within the shaded area shown in the illustration for your specific model. Circuit Breaker 15 amp For model 315W, the electrical supply can be located Receptacle 3-prong grounding-type anywhere on the back wall of the opening.

  • Page 72: Door Panels

    Wine Storage Door Panels Overlay Panels Unless you are installing a stainless steel model, you will MODELS 315W AND 424G need to provide a frame for the glass door. If you order a The overlay panel applied to models 315W and 424G stainless steel unit, models 315W, 424G, 424FSG and should not be confused with the built-in overlay panel WS-30 will be shipped with their panels and hardware...
  • Page 73 Wine Storage subzero.com/specs Integrated Panels MODELS 427G AND 427RG Integrated Panels 427G The integrated full panels or frame panels for glass doors Door " " (679) (1927) for these models will follow some of the identical planning 427RG processes used with the integrated line. The installation of Door "...
  • Page 74 Wine Storage Model WS-30 FRAMED PANEL FRAMED PANEL SPECIFICATIONS If the thickness of the framed panel is less than " , it must be backed up with a sheet of shim material to build the total thickness to " . If the panel is thicker than "...
  • Page 75 (2235) (102) Do not exceed overlay panel dimensions, as this could OVERLAY SPACER SPACER PANEL PANEL PANEL cause damage to panels and the Sub-Zero unit. OVERLAY PANEL BACKER PANEL BACKER PANEL TRIM DOOR FRAME GLASS " (8) min "...
  • Page 76 (2235) (102) FLUSH INSET SPACER SPACER PANEL PANEL PANEL Do not exceed flush inset panel dimensions, as this could cause damage to panels and the Sub-Zero unit. FLUSH INSET PANEL BACKER PANEL BACKER PANEL TRIM " (8) min "...
  • Page 77 Contact your authorized Sub-Zero dealer for the proper components and installation instructions. For For additional information on panel reveals, visit the speci- questions relative to the installation, call Sub-Zero at fication library section of our website, subzerotrade.com.
  • Page 78 Dual flush inset panels and dual installation kits are (740) (211) Backer Panel " " (756) (227) available through your authorized Sub-Zero dealer. Refer WINDOW to the illustration and chart for dual flush inset panel Cut-Out 23" " (584) (1581) specifications.
  • Page 79 SIDE VIEW SIDE VIEW Do not exceed the flush inset decorative panel dimensions. Exceeding dimensions could cause Illus. C Illus. D damage to the panels and the Sub-Zero unit. DOOR / DRAWER Panel Offsets Illus. MODEL WS-30 Doors (hinge) / Grille Sides "...
  • Page 80 Stainless steel side panels end of this section for a profile of the door frame and are also available through your authorized Sub-Zero dealer. position of the glass. Do not drill through the glass. The side panel will need to be a minimum of 24"...
  • Page 81 Door Frame Profile These optional accessories are available through your FULL-SCALE TEMPLATE authorized Sub-Zero dealer. For local dealer information, The full-scale template below shows an example of the visit the find a showroom section of our website, door frame profile for wine storage models and the rela- subzero.com.
  • Page 82 Wine Storage Wine Shelf Wood Facing FULL-SCALE TEMPLATE Dimension 315W " For each model, the wine storage shelves have a natural (278) 424G and 424FSG " (495) cherrywood facing. You can replace these strips with 427G and 427RG " (532) wood more complementary to your design and surround- WS-30 "...

  • Page 83: Door Clearance

    Wine Storage subzero.com/specs Door Clearance FULL-SCALE TEMPLATE Model 424G should extend a minimum " beyond the front surface of adjoining cabinetry to allow for the maximum 145° door opening. The unit can be installed flush with adjacent cabinetry, however, there is potential for interference with the panel if the door is opened past 90°.
  • Page 84 MODELS 424G (WINE) AND UC-24BG...

  • Page 85: Undercounter Refrigeration

    Undercounter Refrigeration. Sub-Zero undercounter refrigeration is a helpful addition to a master suite, bar, home office or media room. In the kitchen, a high-volume ice machine is a must for entertaining. The design flexibility of these compact yet roomy units makes them all the more welcome in any room or outdoor kitchen. They’re ready to be fitted with a custom cabinet panel or can be ordered with a stainless steel panel.

  • Page 86: Specifications

    Undercounter Refrigeration Overall Dimensions UNDERCOUNTER MODELS " 23" " 24" (375) (584) (606) (610) " 34" (854) (864) 4" 4" (102) (102) 18" (457) " (645) 6" (152) " (44) MODELS UC-24R, UC-24BG, UC-24C(I) AND UC-24RO MODELS UC-15I(P) and UC-15I(P)O Model UC-15I overall dimensions do not include panel or handle.
  • Page 87 Undercounter Refrigeration subzero.com/specs Opening Dimensions Planning Information UNDERCOUNTER MODELS ELECTRICAL REQUIREMENTS For ice machine models, it is recommended that electrical TOP VIEW supply be placed in an adjacent cabinet. For all other undercounter models, locate the electrical supply within 24" (610) the shaded area shown in the illustration below.

  • Page 88: Drain Pump

    Do not use self-piercing valves. A saddle valve kit is horizontal runs of drain lines must have a " per 12" available through your authorized Sub-Zero dealer. fall. An air gap will likely be required between the unit (305) IMPORTANT NOTE: A reverse osmosis system can be and drain receptacle.
  • Page 89 Undercounter Refrigeration subzero.com/specs Overlay Panel Door Clearance MODELS UC-24R, UC-24C(I) AND UC-15I(P) MODELS UC-24R, UC-24BG AND UC-24C(I) The overlay design allows for a decorative panel to cover Undercounter models can be installed flush with surround- the door trim for a seamless appearance that will comple- ing cabinetry.
  • Page 90 Door Frame Profile These optional accessories are available through your FULL-SCALE TEMPLATE authorized Sub-Zero dealer. For local dealer information, The full-scale template shows the door frame profile for visit the find a showroom section of our website, model UC-24BG and the relationship to the overlay panel subzero.com.
  • Page 91 MODELS UC-24BG AND UC-24C(I) The information and images in this guide are the copyright property of Sub-Zero, Inc. Neither this guide nor any information or images contained herein may be copied or used in whole or in part without the express written permission of Sub-Zero, Inc. ©Sub-Zero, Inc. all rights reserved.
  • Page 92 FULL TWO YEAR WARRANTY* For two years from the date of original installation, your Sub-Zero product warranty covers all parts and labor to repair or replace, under normal residential use, any part of the product that proves to be defective in materials or workmanship.

  • Page 93: Sub-Zero Warranties

    FULL ONE YEAR WARRANTY* For one year from the date of original installation, your Sub-Zero product warranty covers all parts and labor to repair or replace, under normal residential use, any part of the product that proves to be defective in materials or workmanship.
  • Page 94 SUB-ZERO, INC. P. O. BOX 44848 MADISON, WI 53744 SUBZERO.COM 800.222.7820 SZDG 11 / 2011...
