Sub-Zero BI-36UFD Design Manual page 22

Built-In Refrigeration
This design option allows for a flush door and grille. Stainless
steel panels are available as sales accessories. Shown with
tubular handle option to mirror Wolf built-in ovens.
Flush Inset Application
It is necessary to consider the following points when
planning for a flush inset application:
• The flush inset depth is 2
standard opening.
• The flush inset width is 2
standard opening.
• The flush inset height is
standard opening.
• Panel widths increase to achieve the flush inset look.
1
• You must allow a / "
2
of the unit and grille to allow for proper door swing and
airflow.
IMPORTANT NOTE: The flush inset application is not a
separate model. This is an overlay unit in a flush installa-
tion. The same model is used in an overlay or flush inset
application.
Rough opening dimensions for the flush inset application
3
assume the use of a
/ "
4
tions below show the difference between standard and
flush inset installations.
STANDARD INSTALLATION
24"
(610)
OPENING
DEPTH
TOP VIEW
Standard installation.
3
/ " deeper than the
(56)
16
1
/ " wider than the
(64)
2
1
/ " higher than the
(6)
4
reveal around the perimeter
(13)
decorative panel. The illustra-
(19)
FLUSH INSET INSTALLATION
3 / "
WITH (19) PANEL
4
24" 26
(610)
OPENING
DEPTH FLUSH
DEPTH
TOP VIEW
3
2 / "
16
(56)
Flush inset installation.
22
3
/ "
16
(665)
INSET
1
1 / "
4
(32)
