Built-In Refrigeration
Framed Application
PARTIAL FRAMED OPTION
If you choose not to use custom panels above and below
the glasswell for dispenser model BI-42SD or BI-48SD,
a stainless steel insert panel is available as a sales acces-
sory. This accessory kit includes partial framed molding
and stainless steel panel to provide a spill-resistant finish
above and below the glasswell on the refrigerator door
only. The partial framed accessory kit is available through
your authorized Sub-Zero dealer. Refer to panel dimen-
sions for the partial framed option below.
Optional Partial Framed Panels
BI-42SD
Refrigerator Panel
Freezer Panel
BI-48SD
Refrigerator Panel
Freezer Panel
W H
1 9
15 / " 69 / "
(383) (1767)
16 16
7 9
16 / " 69 / "
(418) (1767)
16 16
W H
3 9
18 / " 69 / "
(476) (1767)
4 16
3 9
18 / " 69 / "
(476) (1767)
4 16
Partial framed kit.
subzero.com/specs
H
W W
BI-42SD / BI-48SD
Partial framed option.
