Quick Links
Planning Information
Integrated Model 700TF( I )
All Freezer
Electronic digital
control panel
Adjustable spill-proof
glass shelves
Stationary shelf
Model 700TF
Location of serial
number
Automatic ice maker
(Model 700TFI)
Model 700TFI
with Ice Maker
Front venting with
removable kickplate
The Sub-Zero Model 700TF and
700TFI integrated design accepts custom
wood or stainless steel door and drawer
panels. Stainless steel panels and handles
are available as sales accessories in three
finishes—classic, platinum and carbon.
Dimensions in parentheses are in
millimeters unless otherwise specified.
11/06
With the installation of a harness kit, these appliances are Star-K
compliant to meet strict religious regulations in conjunction with
specific instructions found on star-k.org. You may purchase this
harness kit through your Sub-Zero dealer. To obtain local dealer
information, visit the Locator section of our website, subzero.com.
E
rgonomically, this unit works — doors above the
counter and drawers below counter level. The shallow
depth enables you to view everything quickly and you
can grab those items and be out of the unit quickly.
The drawers have full extension and are a nice way to
bring the items to you and not have to bend down and
look inside for your package.
As with the two drawer freezer, this tall cousin can be
ordered with or without the automatic ice maker.
The door swing must be specified when ordering this
unit.
Seamless
molding
Adjustable door
shelves
Magnetic door /
drawer gaskets
Upper freezer
storage drawer
Lower freezer
storage drawer
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sub-Zero Sub-Zero 700TF
Summary of Contents for Sub-Zero Sub-Zero 700TF
- Page 1 Planning Information Integrated Model 700TF( I ) All Freezer Electronic digital control panel Adjustable spill-proof glass shelves Stationary shelf Model 700TF Location of serial number Automatic ice maker (Model 700TFI) Model 700TFI with Ice Maker Front venting with removable kickplate The Sub-Zero Model 700TF and 700TFI integrated design accepts custom wood or stainless steel door and drawer...
- Page 2 Planning Information Integrated Model 700TF( I ) F E A T U R E S Tall freezer unit with upper cabinet freezer and freezer storage drawers Model 700TFI has automatic ice maker Integrated design for "point-of-use" refriger- ation anywhere in the home Refrigeration system ensures the best food storage and energy efficiency Electronic digital controls are up front and...
- Page 3 Planning Information Integrated Model 700TF( I ) M O D E L O P T I O N S Tall Freezer Unit 700TF Tall Freezer Unit with Automatic Ice Maker 700TFI P A N E L O P T I O N S Integrated (custom panels) Classic Stainless Steel Finish Platinum Stainless Steel Finish...
-
Page 4: Top View
Planning Information Integrated Model 700TF( I ) I N S T A L L A T I O N S P E C I F I C A T I O N S *PLACEMENT OF THE ANTI-TIP BRACKET SHOULD BE 24" (610) FROM THE FRONT OF THE UNIT WITHOUT PANELS TO THE BACK OF THE... - Page 5 Planning Information Integrated Model 700TF( I ) I N S T A L L A T I O N N O T E S Refer to the illustrations and specifications for overall dimensions, finished rough opening dimensions and installation specifics. IMPORTANT NOTE: The depth of Model 700TF(I) is 24"...
- Page 6 Planning Information Integrated Model 700TF( I ) As the reveal between cabinets and the Integrated unit decreases, the potential exists for severe finger pinching or crushing if a hand or fingers are placed in the opening when the door is closing. Dimensions in parentheses are in millimeters unless otherwise specified.
- Page 7 Planning Information Integrated Model 700TF( I ) F R A M E D C A B I N E T R Y SUB-ZERO (610) UNIT TO WALL CABINET FRAME CABINET PANEL " (3) DOOR REVEAL (686) Traditional Frame – full overlay (top view). SUB-ZERO (610) UNIT...
- Page 8 Planning Information Integrated Model 700TF( I ) F R A M E D C A B I N E T R Y – B E A D E D I N S E T A P P L I C A T I O N 24"...
- Page 9 Planning Information Integrated Model 700TF( I ) F R A M E L E S S C A B I N E T R Y "* (679) PANEL WIDTH " (1153) " (345) (876) "* (424) 4"* (102) 27" (686) TOE KICK FINISHED OPENING A) ALL REVEALS ARE 1/8"...
- Page 10 Planning Information Integrated Model 700TF( I ) P A N E L C O N S I D E R A T I O N S The illustrations below provide panel width dimensions for installation of a 27" (686) wide tall unit and for installing two 27"...
- Page 11 Planning Information Integrated Model 700TF( I ) CABINETS (635) (686) TOP VIEW Installation without side panels. CABINETS (635) (686) MINIMUM " (16) SIDE PANELS Installation with side panels. CABINETS (635) (1372) TOP VIEW Installation of two units side by side. CABINETS (635) (686)
- Page 12 Planning Information Integrated Model 700TF( I ) U P P E R V A L E N C E D E T A I L 2 (38) (1153) BOTTOM DOOR PANEL (2032) FLOOR FINISHED HEIGHT OF 80" (2032) IS TO TOP OF SUB-ZERO MOLDING Dimensions in parentheses are in millimeters unless otherwise specified.
- Page 13 Planning Information Integrated Model 700TF( I ) T O E K I C K A R E A D E T A I L (268) PANEL (424) PANEL (254) OPTIONAL (102) Dimensions in parentheses are in millimeters unless otherwise specified. T O E K I C K C L E A R A N C E The toe kick clearance can vary with the height of the lower drawer panel;...
- Page 14 Planning Information Integrated Model 700TF( I ) F R A M E D C A B I N E T R Y IMPORTANT NOTE: The depth of each Integrated unit is 24" (610) from the front of the unit to its back.
- Page 15 Planning Information Integrated Model 700TF( I ) F R A M E L E S S C A B I N E T R Y IMPORTANT NOTE: The depth of each Integrated unit is 24" (610) from the front of the unit to its back.
