Sub-Zero BI-36UFD Design Manual page 39

Built-In Refrigeration
Overlay Panel Thickness
FULL-SCALE TEMPLATE
Overlay and flush inset panels must be a minimum of
thick to support mounting the handle. Panel thickness
(16)
does not include backer and spacer panel. Mount handle
close to the opening edge of the door.
PANEL THICKNESS
OVERLAY AND FLUSH INSET APPLICATIONS
DEPTH OF TUBULAR
AND PRO HANDLES
1" 2"
(25) (51)
1
/ "
BACKER PANEL
4 (6)
DOOR
5
/ "
8
3"
(76)
1
1 / "
4 (32) PANEL
1"
(25) PANEL
3
/ "
4 (19) PANEL
.10"
(3) SPACER PANEL
39
subzero.com/specs
