Sub-Zero BI-36UFD Design Manual page 40

Sub-zero design guide
Hide thumbs Also See for BI-36UFD:
Table of Contents

Advertisement

Built-In Refrigeration
Overlay Application
FULL-SCALE TEMPLATE
7
23
/
"
8
(606)
TO REAR OF UNIT
1"
(25) THICK
PANEL
3
/
"
(19) THICK
4
OVERLAY PANEL
(TYPICAL)
1
/
"
4
(6) BACKER
PANEL
DOOR OPENING 90°
TOP VIEW
OVERALL WIDTH OF UNIT
40
0"
1"
(25)
SCALE
