* POWER SUPPLY
+12 to 24 VDC Max
+
NC
NO
*LOCK
RELAY
26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9
TOP OF THE
HAND READER
* These components are not supplied by Recognition Systems, Inc.
** The operation of the Auxiliary Inputs depend upon how the inputs have been configured.
Figure 17-4: Lock Output Wiring Diagram
-
*ELECTRIC LOCK
+
OR STRIKE
-
HandKey II Manual
SWITCH LEGEND
N.O. MOMENTARY*
N.C. DOOR SWITCH*
WALL TO WHICH
THE HAND READER
IS ATTACHED
12 to 24 V
AC/DC
Input
8
7
6
5
4
3
2
1
-
+
4-Wire
RS-422
Connection
Page 83
HINGE
