Wiring Connections
Figure 5-4: Card Reader Emulation Mode Wiring Diagram
Page 30
WALL TO WHICH
THE HAND READER
IS ATTACHED
12 to 24 V
AC/DC
Input
14 13 12 11 10 9
18 17 16 15
1
2
RS-422
Connection
TOP OF THE
HAND READER
NOTE: For +12 VDC readers, connect power supply +12 VDC to card reader.
Access Panel
GROUND
DATA 1
DATA 0
8 7 6
5 4
Card Reader
GROUND
DATA 1
DATA 0
+5 VDC POWER
(SEE NOTE BELOW)
HINGE
3
2 1
