Mechanical Installation; Wall Plate Installation - Recognition Systems HANDKEY II Manual

Mechanical Installation

Select an installation location based on the guidelines provided in the Planning
an Installation section beginning on page 9.
Wall Plate
Installation
For the following instructions protect the HandReader from the dust and debris
NOTE
generated during the wall plate installation process.
1. Remove the wall plate from the packing carton. Refer to Figure 4-1 for all
2 UPPER SCREWS
Figure 4-1: Wall Plate
2. Measure and mark a point 48 1/2 inches (123 cm) from the surface of the
3. For a hollow wall, drive a small nail into the wall at the mark and hang the
4. For a solid wall, hold the wall plate against the wall, centering the leveling
wall plate references in the following section.
finished floor. This point will correspond to where the top-center point of the
HandReader should be mounted.
wall plate from the leveling hole located near the top of the wall plate.
hole over the mark in the wall.
HOLE
SURFACE
CONDUIT
ENTRY
