Wiring Connections
Figure 5-2: Lock Output Wiring Diagram
Page 28
SWITCH LEGEND
N.O. MOMENTARY*
N.C. DOOR SWITCH*
12 to 24 V
AC/DC
Input
14 13 12 11 10 9
1 2 18 17 16 15
RS-422
Connection
TOP OF THE
HAND READER
* These components are not supplied by Recognition Systems, Inc.
** The operation of the Auxiliary Inputs depend upon how the inputs have been configured.
* POWER SUPPLY
+12 to 24 VDC Max
-
+
NC
*ELECTRIC LOCK
NO
*LOCK
+
RELAY
WALL TO WHICH
THE HAND READER
8 7 6 5 4 3 2 1
OR STRIKE -
IS ATTACHED
HINGE
