Specifications - Recognition Systems HANDKEY II Manual

Introduction

Specifications

Size:
Power:
Weight:
Wiring:
Temperature:
Relative Humidity Non-
Condensing:
Verification Time:
Memory Retention:
Transaction Buffer:
ID Number Length:
Baud Rate:
Communications:
User Capacity:
Card Reader Input:
Card Reader Output:
Duress Code:
Door Controls:
Alarm Monitoring:
Event Monitoring:
Time Zones:
Auxiliary Outputs
Page 6
Table 1: Specifications
8.85 inches wide by 11.65 inches high by 8.55 inches deep (22.3 cm)
22.3 cm wide by 29.6 cm high by 21.7 cm deep
12 to 24 VDC or 12 to 24 VAC 50-60 Hz, 7 watts
6 lbs (2.7 kg)
2 twisted-pair, shielded, AWG 22 or larger (such as Belden 82732)
-10C to +60C – non-operating/storage (14F to 140F)
0C to 45C – operating (32F to 113F)
5% to 85% – non-operating/storage
20% to 80% – operating
1 second or less
5 years using a standard internal lithium battery
5120 transactions
1 to 10 digits
300 to 28.8 K bps
RS-232, RS-422, RS-485 2-wire, optional Ethernet, optional Modem
512 users expandable to 32,512
Proximity, Wiegand, Magnetic Stripe, Bar Code
(5 VDC provided by HandReader)
Wiegand, Magnetic Stripe, Bar Code
1 leading digit, user definable
Request to Exit input, Door Switch input, Lock output
(open collector, 5 VDC present, sinks to ground, 100 mA max)
Tamper, Door Forced, Duress
There is a variety of monitoring options including events such as:
Invalid ID, Time Zone Violation, ID Refused, Try Again,
Power Failure
62 total – 2 fixed, 60 programmable
3 user definable
(open collector, 5 VDC present, sinks to ground, 100 mA max)
