Recognition Systems HANDKEY II Manual page 31

SWITCH LEGEND
N.O. MOMENTARY*
N.C. DOOR SWITCH*
12 to 24 V
AC/DC
Input
18 17 16 15
1 2
RS-422
Connection
TOP OF THE
HAND READER
* These components are not supplied by Recognition Systems, Inc.
** The operation of the Auxiliary Inputs depend upon how the inputs have been configured.
Figure 5-3: Auxiliary Output Wiring Diagram
* POWER SUPPLY
+12 to 24 VDC Max
+
*AUX
RELAY
14 13 12 11 10 9 8 7
HandKey II Manual
-
NC
*AUXILIARY
NO
+
DEVICE
WALL TO WHICH
THE HAND READER
IS ATTACHED
6 5 4 3 2 1
-
HINGE
Page 29
