Mechanical Installation
5. Align a bubble level with the top edge of the wall plate and gently rotate the
6. Secure the plate to the wall using heavy masking tape.
7. Using the wall plate as a template, mark the locations of the two upper screw
8. For a concealed wiring connection, trace the outline of the open area in the
9. For a surface conduit wiring connection, mark the two conduit clamp holes
10. Remove the wall plate, masking tape, and the nail (if used).
Mounting the 1. For a hollow wall, use the provided hardware to mount the wall plate. Use the
Wall Plate
2. For a solid wall, use expansion bolts to mount the wall plate. For all five
Routing the 1. For a concealed wiring connection, drill a 1/2 inch hole in a convenient loca-
Wiring
2. For a surface conduit wiring connection, drill a 1/4 inch diameter hole, 1/4 of
Attaching the 1 Remove the HandReader from its carton.
HandReader 2. Align the sleeves of the back plate with the pins of the wall plate and slide the
Page 22
wall plate until the bubble level shows that the top edge of the wall plate is
level.
holes and the three lower screw holes.
center of the wall plate. Identify and mark a 1/2 inch hole through which the
HandReader's wiring will be mounted.
at the right side of the wall plate.
two auger style fasteners for the upper two mounting holes. Use the toggle
bolts for the three lower mounting holes.
mounting holes, drill a 1/4 inch diameter hole, 1/4 of an inch deeper than the
length of the expansion anchor.
tion within the open area of the wall plate. Pull the wiring to enter the Han-
dReader through this hole in the open area.
an inch deeper than the length of the expansion anchor for each of the two
conduit clamp holes. Route 1/2 inch conduit to the HandReader, ending the
conduit between the two conduit clamp holes. Pull the wiring to enter the
HandReader through the conduit.
HandReader to the left as shown in figure 4-2.
